Vertical Pre-vacuum Nitrogen-protected Transverse Magnetic Furnace
Working Dimensions
Φ500×1400mm
Overall Dimensions
1900×1900×2500mm
Maximum Operating Temperature
650℃
Total Furnace Weight
5T
Rated Voltage
380V、50HZ
Rated Power
70KW (Magnetic field power: 11KW, Heating power: 45KW)
Transverse Magnetic Field Intensity
Customizable
Heating Zones
3 Zones
Heating Rate
1℃/min
Cooling Rate
5℃/min
Temperature Control Mode
Japanese Ohtori temperature module, PID intelligent temperature control, with over-temperature alarm and power-off function, multi-segment temperature control
Our Vertical Pre-vacuum Nitrogen-protected Transverse Magnetic Furnace is independently developed for high-precision heat treatment and magnetic field annealing of amorphous and nanocrystalline magnetic cores. Equipped with an advanced Japanese Ohtori temperature control module and a customizable transverse magnetic field system, the equipment realizes automatic pre-vacuum processing, precise nitrogen protection, intelligent multi-segment temperature control, and uniform magnetic field annealing without manual intervention.
Backed by a full set of independent patents, our equipment features a modular design, user-friendly operation, and low maintenance costs. We offer free customized thermal process solutions, prototype testing, on-site installation, staff training, and lifelong technical after-sales service to help magnetic component manufacturers optimize their annealing processes, reduce energy consumption, and significantly improve the magnetic performance consistency of their products.
Product Form
Specification Customization: Adapt to Special Dimensions
Note: Other dimmension and performance can be customized
Product Application
Inverter Magnetic Cores：Core applications in power electronic inverters, switching power supplies and UPS uninterruptible power supplies. With high frequency, low loss and high saturation magnetic flux density characteristics, provides efficient and stable magnetic foundation for power conversion, ensuring reliable operation of power equipment.
Common-mode Magnetic Cores：Widely used in EMI electromagnetic interference filtering, power input/output noise reduction and signal line anti-interference. Effectively suppresses common-mode noise in circuits, significantly improves electromagnetic compatibility (EMC) of electronic equipment, ensuring compliance with industry standards.
Magnetizing Current Transformers：Suitable for precision current transformers, metering instruments and power monitoring systems. Utilizing high permeability and excellent linearity, achieves precise acquisition, isolation and transmission of tiny current signals, being a key component ensuring power metering accuracy and monitoring reliability.
Nanocrystalline Magnetic Cores：Deeply empowering the new energy industry, covering core scenarios such as photovoltaic inverters, energy storage systems, EV charging piles and wind power converters. With advantages of low loss and high permeability, improves energy conversion efficiency and promotes efficient utilization of green low-carbon energy.
